MV AMIRA MIRUNA
DWT 33.738 TONS AT 9.826 MTRS SSW ,TPC 45.06 MT
BLT 2010 ,Shin Kochijyuko Co , JAPAN
TYPE: SINGELDECK / BULK CARRIER , DOUBLESKIN HOLD 1/5,
BOXSHAPED HOLD / LOG BULK CARRIER
CLASS NK / FLAG PANAMA  / THE AMERICAN P&I CLUB
LOA 176.83 M, BEAM 28.8 M
GT/NT 21100/10772
5 HO/5 HA
GRAIN (m3)                                     BALE (m3)
No. 1:  6192.17                             6079.52
No. 2:  9534.52                             9282.23
No. 3:  9567.51                             9287.53
No. 4:  9562.85                             9282.87
No. 5:  8497.95                             8228.23
TOTAL 43355 CBM GRAIN,   42160.38 CBM BALE

DIMS
hold         length             A Beam             M beam    F Beam       height
No. 1:      24.00 m         25.20 m             19.60 m    10.80 m      12.42 m
No. 2:      28.80 m         26.40 m                                                            12.42 m
No. 3:      28.80 m         26.40 m                                                            12.42 m
No. 4:      28.80 m         26.40 m                                                            12.42 m
No. 5:      28.00 m         9.40 m                 19.20 m     24.00 m     12.42 m

HATCH SIZE: (l)       (w)
No. 1:      13.60 m x 15.40 m
No. 2/5:    20.00 m x 20.00 m
Type of hatch covers: Weather tight MacGregor hydraulic folding type

CR 4 X 30 TS
Max outreach beyond ship’s rails : 9.6 m
VESSEL IS GRAB FITTED ( SUB SPECS OF GRABS ) BUT GRABLESS
MAXIMUM  LIFT CAP IN GRAB/ BUCKET MODE 24 TONS ( GROSS)

Ventilation: yes ( mechanical )
CO2 fitted in holds.
Australian hold ladders: fitted in all holds according to Australian requirements
Log fitted : collapsible stanchions

ADA

MV AMIRA DIANA

EX NAME DIANA T
DWT 36009 TONS AT 10.276 MTRS SSW ,TPC 48.84 MT
BLT 2010 , SAMJIN , CHINA
TYPE: SINGELDECK / BULK CARRIER
CLASS NK / FLAG BARBADOS / AMERICAN PANDI
LOA 180 M, BEAM 30 M
GT/NT 23426/12146
5 HO/5 HA
GRAIN (M3)                                                        BALE (M3)
NO. 1:  7742.8                                      7433.1
NO. 2:  9764.7                                      9374.1
NO. 3:  9809.6                                      9417.2
NO. 4:  9821.3                                      9428.5
NO. 5:  9146.4                                      8780.5
TOTAL: 46284.8 CBM GRAIN,      44433.4 CBM BALE

DIMS
HOLD    LENGTH                                BEAM              HEIGHT
NO. 1:  23.00 M          26.10 M          15.10 M
NO. 2:  26,00 M          27.10 M          15.10 M
NO. 3:  26,00 M          27.10 M          15.10 M
NO. 4:  26,00 M          27.10 M          15.10 M
NO. 5:  26,00 M          27.10 M          15.10 M

HATCH SIZE: (L)       (W)
NO. 1:      16 X 18.4 X 13.7 M
NO. 2/5:    19.2 X 20.20
TYPE OF HATCH COVERS: WEATHER TIGHT MACGREGOR HYDRAULIC FOLDING TYPE

CR 4 X 25 TS
VESSEL IS GRAB FITTED ( SUB SPECS OF GRABS ) BUT GRABLESS
MAXIMUM  LIFT CAP IN GRAB/ BUCKET MODE 24 TONS ( GROSS)

LOG FITTED
CO2 FITTED IN HOLDS.
SMOKE DETECTION SYSTEM , IN CONNECTION WITH CO2 SYSTEM
AUSTRALIAN HOLD LADDERS: FITTED IN ALL HOLDS ACCORDING TO AUSTRALIAN REQUIREMENTS

ADA

MV AMIRA IRINI

FLAG: SAN MARINO

SUMMER DEADWEIGHT: 35,313 MTS ON 10.42 M DRAFT, TPC 44.0 MT
WINTER DEADWEIGHT: 34,356 MTS ON 10.20 M DRAFT, TPC 43.9 MT
TPC AT SUMMER DRAFT 44.0 MT
BUILT IN 2004 IN JAPAN AT SHIKOKU DOCKYARD
CLASS: NK, NEXT DD: 5/2027, NEXT SS: 5/2029
P+I: AMERICAN
GROSS: 21,059 / NET: 11,954
LOA: 175.6 M – BREADTH 28.4 M – DEPTH 14.8 M
HOLDS / HATCHES: 5 / 5
GRAIN / BALE: 46,185 / 44,052 CBM (1,631,037 / 1,555,694 CBFT)

GRAIN / BALE BREAKDOWN
	GRAIN (M3)	BALE (M3)
HOLD NO.1	7,458.20	7,087.90
HOLD NO.2	9,748.60	9,283.69
HOLD NO.3	9,824.00	9,308.27
HOLD NO.4	9,908.80	9,427.99
HOLD NO.5	9,245.80	8,944.07
TOTAL	46,185.40	44,051.92



HATCH COVER SIZES (M)
HATCH NO.1	18.50 x 4.60
HATCH NO.2	20.75 x 9.20
HATCH NO.3	20.75 x 9.20
HATCH NO.4	20.75 x 9.20
HATCH NO.5	20.75 x9.20



HOLD DIMENSIONS (M)		NO.1	NO.2	NO.3	NO.4	NO.5
LENGTH		27.00	27.75	27.75	27.75	27.00
BREADTH	F	13.06	28.31	28.31	28.31	28.31
	M	23.95	28.31	28.31	28.31	28.31
	A	28.31	28.31	28.31	28.31	26.56
HEIGHT		13.93	13.93	13.93	13.93	13.93



TTOP DIMENSIONS (M)		NO.1	NO.2	NO.3	NO.4	NO.5
LENGTH		27.00	27.75	27.75	27.75	27.00
BREADTH	F	6.53	20.90	20.90	20.90	20.90
	M	18.29	20.90	20.90	20.90	17.40
	A	20.90	20.90	20.90	20.90	10.01



STRENGTHENED FOR HEAVY CARGOES: TT 18.00 MT/SQM
TT ON DECK NO 1: 4.3 MT/SQM, NO 2/3/4/5: 4 MT/SQM
TT ON HATCVRS NO 1: 4.5 MT/SQM, NO 2/3/4/5: 1.75 MT/SQM
GEAR: 4 X 30T CRANES
CO2 FITTED IN HOLDS / FULLY APPENDIX-B FITTED



ADA WOG

MV AMIRA NORA (ex IVS Sunbird )

DWT 33.399 TONS AT 9.826 MTRS SSW ,TPC 45.256 MT
BLT 2015 ,Shin Kochijyuko Co , JAPAN
TYPE: SINGELDECK / GENERAL CARGO, DOUBLESKIN HOLD 1/5,
BOXSHAPED HOLD / LOG BULK CARRIER
CLASS NK / FLAG PANAMA  / THE AMERICAN P&I CLUB
LOA 176.83 M, BEAM 28.8 M
GT/NT 21181/10765
5 HO/5 HA
GRAIN (m3)                                     BALE (m3)
No. 1:  6278.25                             6465.47
No. 2:  9538.81                             9365.35
No. 3:  9575.27                             9400.21
No. 4:  9502.36                             9326.94
No. 5:  8310.71                             8145.15
TOTAL43205.4 CBM GRAIN, 42503.12 CBM BALE

DIMS
hold         length             A Beam             M beam    F Beam       height
No. 1:      24.00 m         25.40 m             18.20 m    7.80 m         14.35 m
No. 2:      28.80 m         26.40 m                                    25.60m      14.35 m
No. 3:      28.80 m                                         26.40 m                             14.35 m
No. 4:      28.80 m         24.40 m                                    26.40 m      14.35 m
No. 5:      28.00 m         9.20 m                17.00 m     24.40 m     14.35 m

HATCH SIZE: (l)       (w)
No. 1:      13.60 m x 15.40 m
No. 2/5:    20.00 m x 20.00 m
Type of hatch covers: Weather tight MacGregor hydraulic folding type

CR 4 X 30 TS
Max outreach beyond ship’s rails : 9.6 m
VESSEL IS GRAB FITTED ( SUB SPECS OF GRABS ) BUT GRABLESS
MAXIMUM  LIFT CAP IN GRAB/ BUCKET MODE 24 TONS ( GROSS)

Ventilation: natural
CO2 fitted in holds.
A60 Bulkhead
Australian hold ladders: fitted in all holds according to Australian requirements
Log fitted : collapsible stanchions

ADA

M/V AMIRA SAHAR

FLAG PANAMA
SUMMER DWT 38.477 DWT ON 10.02 M – TPC 51.31 MT
BLT APR/2012, NAIKAI ZOSEN CORPORATION SETODA SHIPYARD
CLASS NK
THE AMERICAN P&I CLUB
GRT 23,855 / NRT 11,814 – IMO NO. 9527958
STRENGTHENED FOR HEAVY CARGO – HOLDS NO. 2 AND 4 MAY BE LEFT EMPTY
DIMS: 184.75M LOA X 177.00M LBP X 30.60M BEAM X 14.50M DEPTH(MOULDED )
5 HO / 5 HA – HYDRAULIC FOLDING TYPE HATCH COVER (MACGREGOR)

HOLDS  CAP
No1 : 7592.4 GR / 7410.0 BL
No2 : 10304.9 GR / 10082.8 BL
No3 : 10304.9 GR / 10082.9 BL
No4 : 10360.1 GR / 10175.3 BL
No5 : 8673.6 GR / 8564.6 BL
TTL : GRAIN 47235 CBM / BALE 46316.5 CBM OR
TTL : 1.668.083 CBFT GRAIN CAP   /    1.635.647 CBFT BALE CAP
47.235,90 M3 GRAINS / ABT 46.315,50 M3 BALE

HATCH DIMS
No1: 15.5 M * 17.60 M
No2/3/4/5 : 20.80 M * 20.80 M
HO DIMS
No1 : 20.2 * 3.2 * 25.4 MTRS
No2 : 28.4 * 20.8 * 21.0 MTRS
No3 : 28.4 * 21.0 * 21.0 MTRS
No4 : 32.2 * 20.8 * 20.8 MTRS
No5 : 28.4 * 21.4 * 21.4 MTRS

BOX-SHAPED (HOLDS: 2 – 5)
CO2 FITTED
FITTED WITH AUSTRALIAN LADDERS
GEARS: 4 X 30 TONS CRANES (MITSUBISHI ELECTRO-HYDRAULIC)
VESSEL IS GRAB FITTED ( SUB SPECS OF GRABS ) BUT GRABLESS
MAXIMUM  LIFT CAP IN GRAB/ BUCKET MODE 24 TONS ( GROSS)
ADA

M/V AMIRA LOULIA
2008
NKK
LOA / LBP /BM 177.13 / 168.5 / 28.4 M
DWT 32271,31 MT AT 10.02 M SSW TPC 43.84
WINTER / TROPICAL DWT: 31359.52 / 33186.74
GROSS TONAGE / NET TONAGE 20236 / 10947
GRAIN/BALE 42595 / 41124 CBM
HOLD/HATCHES: 5/5, – MOULDED DEPTH: 14,25 m
HOLD DIMENSIONS: (L x B (fwd/aft) x H) HOLD 1: 23.95 X 6.35 / 23.95 X 14.1 m; HOLD
2-4: 28.0 X 23.95 / 23.95 X 14.1 m; HOLD 5: 26.65 X 23.95 / 9.55 X 14.1 m”
CAPACITY BY HOLDS GRAIN/BALE: HOLD 1: 5792/5608; HOLD 2: 9500/ 9147; HOLD 3:
9500/9147; HOLD 4: 9500/9147; HOLD 5: 8303/8075 CBM
2 X GENS
NOT LOGS FITTED
SQUARED BOXED HOLDS (HOLDS N. 2/3/4)
CO2 FITTED IN HOLDS
IWS
BWTS
CARGO CRANES: 4 X 30.5 MT SWL
CO2 FITTED
ADA WOG

MV AMIRA LAYLA

Flag : San Marino
Where / When Built: Hakodate / 2009
32,047 tons deadweight on 9.64 m ssw
31,145 tons deadweight on 9.44 m wsw
32,953 tons deadweight on 9.84 m tsw

Type: Singeldeck / Bulkcarrier doubleskin hold 1/5, boxshaped hold 2/3/4
except for topside tanks

IMO No.: 9412622
Classification No.: NK 092054

Gross / Net tonnage: 19,846 / 10,514
Panama Net tonnage: 16,570
Suez Gross / Net tonnage: 20,228.64 / 18,225.50

Main dimension:
– L.O.A.: 175,53 m
– Beam: 29,40 m
– Moulded depth: 13,70 m
– TPC: 45,22 mt

Cargo gear: 4 Electro-Hydraulic Cranes at 30 mt SWL situated between holds 1-2, 2-3, 3-4, 4-5

The cranes are not combinable.

Hatches/Holds: 5/5

Hatch size: No. 1: 12,75 m x 13,60 m
No. 2/5: 19,55 m x 19,60 m

Type of hatch covers: Weather tight MacGregor hydraulic folding type

Hold capacity:
Grain (m3)
No. 1: 5,493.94
No. 2: 9,077.28
No. 3: 9,077.28
No. 4: 9,077.28
No. 5: 8,178.34
TOTAL: 40,904,12

Bale (m3)
No. 1: 5,416.80
No. 2: 8,754.54
No. 3: 8,757.89
No. 4: 8,757.89
No. 5: 7,930.77
TOTAL: 39,617.89

Hold dimensions:
hold length beam height    height up to top h/coaming
No. 1: 25,25 m  B/F 5.95 m 12,11 m     13.81m
B/A 25,50 m
No. 2: 28,05 m 25,50 m 12,11 m     13.81m
No. 3: 28,05 m 25,50 m 12,11 m     13.81m
No. 4: 28,05 m 25,50 m 12,11 m     13.81m
No. 5: 27,20 m B/F 25,50 m 12,11 m     13.81m
B/A 10.20 m

Alternate hold loading: possible
